SIHF PVC Insulation Sheath Multi Core Sensor Cable Control Fine Wire 4X0.5mm2 4 Core

Product Categories
Shanghai Dingzun Electric&Cable Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

SIHF PVC Insulation Sheath Multi Core Sensor Cable Control Fine Wire 4X0.5mm2 4 Core

Brand Name : dingzun

Model Number : y-02

Certification : ul

Place of Origin : shanghai

MOQ : 200M

Price : 1M/0.45~4USD

Payment Terms : L/C, T/T

Supply Ability : 1000M/1DAYS

Delivery Time : 15DAYS

Packaging Details : ROLL

BRAND : Dingzun

C/O : CHINA

Conductor : Tinned copper

Stranded : Stranded

Construction : 4*0.5MM2

Insulation : PVC

shield : NO

Armor : NO

SHEATH : PVC

Temperature : 90C

Voltage : 600V

Packing : 100M/ROLL

Application : CONTROL CABLE

CORES : 4

Contact Now

Details:SIHF

No of

Con .

 Size AWG Stranding Drain Wire AWG

Insulation

Thick .

 Jacket Thickness N . O . M O . D . Colour Code Weight #/MFT
3 24 7/32 24 0 .010" 0 .020" 0 . 137" 1 14
4 24 7/32 24 0 .010" 0 .020" 0 . 148" 1 16
5 24 7/32 24 0 .010" 0 .020" 0 . 155" 1 18
6 24 7/32 24 0 .010" 0 .023" 0 . 180" 1 22
7 24 7/32 24 0 .010" 0 .023" 0 . 187" 1 30
8 24 7/32 24 0 .010" 0 .023" 0 . 196" 1 34
9

24 7/32

24 7/32

24

24

 0 .010" 0 .010" 0 .023" 0 .023" 0 .205" 0 .214"

1

1
10 40
12 24 7/32 24 0 .010" 0 .023" 0 .229" 2 46
15 24 7/32 24 0 .010" 0 .023" 0 .250" 2 54
20 24 7/32 24 0 .010" 0 .023" 0 .280" 2 66
25 24 7/32 24 0 .010" 0 .030" 0 .321" 2 82
30 24 7/32 24 0 .010" 0 .030" 0 .345" 2 94
40 24 7/32 24 0 .010" 0 .030" 0 .388" 2 120
50 24 7/32 24 0 .010" 0 .035" 0 .480" 2 146
2 22 7/30 24 0 .010" 0 .020' 0 . 142" Black/Red 14
3 22 7/30 24 0 .010" 0 .020' 0 . 150" 1 16
4 22 7/30 24 0 .010" 0 .020' 0 . 163" 1 20
5 22 7/30 24 0 .010" 0 .023" 0 . 182" 1 30
6 22 7/30 24 0 .010" 0 .023" 0 . 194" 1 34
7

22 7/30

22 7/30

24

24

 0 .010" 0 .010" 0 .023" 0 .023" 0 .205" 0 .217"

1

1
8 42
9 22 7/30 24 0 .010" 0 .023" 0 .227" 1 46
10 22 7/30 24 0 .010" 0 .023" 0 .236" 1 50
12 22 7/30 24 0 .010" 0 .023" 0 .253" 1 56
15 22 7/30 24 0 .010" 0 .023" 0 .277" 2 70
19 22 7/30 24 0 .010" 0 .030" 0 .319" 2 86
25 22 7/30 24 0 .010" 0 .030" 0 .356" 2 110
30

22 7/30

22 7/30

24

24

 0 .010" 0 .010" 0 .030" 0 .030" 0 .383" 0 .434"

2

2
40 164
50 22 7/30 24 0 .010" 0 .035" 0 .485" 2 200
2

22

22

 0 .010" 0 .010" 0 .023" 0 .023" 0 . 167" 0 . 176" Blk/Red 1
3 20 7x28 28
4 20 7x28 22 0 .010" 0 .023" 0 . 191" 1 34
5 20 7x28 22 0 .010" 0 .023" 0 . 199" 2 38
7 20 7x28 22 0 .010" 0 .023" 0 .232" 2 50
8

22

22

 0 .010" 0 .010" 0 .023" 0 .030" 0 .243" 0 .255"

2

2
9 20 7x28 62
12 20 7x28 22 0 .010" 0 .030" 0 .287" 2 78
15 20 7x28 22 0 .010" 0 .030" 0 .322" 2 92
19 20 7x28 22 0 .010" 0 .030" 0 .354" 2 112
25 20 7x28 22 0 .010" 0 .030" 0 .396" 2 140

This 4 core PVC insulated and sheathed control cable is from one of our most popular multi core control and sensor cable series.

0.5mm2 section area is very common size, PVC material is suitable for most electrical appliances and instruments, thanks to its oil resistance, flame retardant , flexible performances and economic characteristic.

Our client uses it for a car inside sensor, which needs strict flame-retardant standard, we always choose premium PVC material to meet client’s requirement

Multi core sensor or control cable is main product for Dingzun cable, we hereby listed daily use parameters covering various gauges and cores/conductors. We provide this chart to give quick accessibility to our clients for easy selection.

SIHF PVC Insulation Sheath Multi Core Sensor Cable Control Fine Wire 4X0.5mm2 4 Core

SIHF PVC Insulation Sheath Multi Core Sensor Cable Control Fine Wire 4X0.5mm2 4 Core

SIHF PVC Insulation Sheath Multi Core Sensor Cable Control Fine Wire 4X0.5mm2 4 Core

SIHF PVC Insulation Sheath Multi Core Sensor Cable Control Fine Wire 4X0.5mm2 4 Core
